Dust cover swingarm original | Piaggio SI, Boxer

Pedals angular | Piaggio Ciao. SI, Bravo

Drive: Outer edge · Material: Plastic · Surface: ribbed · Thread type: FG14.3 (9/16" 20G) · Total length: 118 mm · Height: 29 mm · Color: black · Width: 51 mm · Reflectors: Yes · Width across flats SW: 15 mm

Stand set | Piaggio SI

Manufacturer: Made in Italy · Material: Steel · Surface: varnished · Stand base - center mount (A): 225 mm · Total width of stand base (B): 220 mm · Wide receptacle (C): 89 mm · Ø Receptacle (D): 14 mm · Total height: 265 mm · Wide upright foot (F): 20 mm · Color: black

Fuel tap vertical M12x1 (with union nut) outgoing right | Piaggio SI

Manufacturer: Made in Italy · Possible lever positions: open / closed / reserve · Thread type: MF12x1 (fine pitch thread) · Material lever: Plastic · Filter type: Plastic net · Mounting type: Union nut · Installation direction: vertical / vertical · Outlet direction: right · Spare tube shape: straight · Ø fuel hose connection: 6 mm · Reserve level: 65 mm

Footboard (pair) black | Piaggio SI

Manufacturer: Made in Italy · Material: Plastic · Total length: 377 mm · Number of fixing points: 4 pcs · Height: 35 mm · Color: black · Width: 58 mm · Width: 116 mm · Piaggio OEM number: 267611

Lockable fuel filler cap

Manufacturer: Made in Italy · Material: Cast aluminum · Material: Plastic · Fuel filler cap: Bayonet 30 mm · Lockable: Yes · Ø External head: 64.5 mm · Ø outside connection piece: 53 mm · Height: 41 mm · Color: black

Olympia swingarm axle set | Piaggio SI, Bravo, Boxer, Grillo

Drive: External hexagon · Manufacturer: Olympia · Ø axle: 10 mm · Material: Steel · Surface: galvanized (blue) · Thread type: M10x1.5 (standard thread) · Ø outside: 14 mm · Ø inside: 10 mm · Total length: 120 mm · Ø External bearing: 20 mm · Color: silver

Oil seal NBR 25.7/35/9 B DUO original fork | Piaggio SI

Simmering type: B DUO - With sheet metal outer casing / two sealing lips. · Manufacturer: Piaggio · Material: NBR · Ø outside: 35 mm · Ø inside: 25.7 mm · Width: 7 mm · Width: 9 mm · Temperature resistance (min.): -30 - 100 °C

GPO control bearing set | Piaggio SI, Bravo

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Thread type: MF27.5x1 (fine pitch thread) · Bearing type: Bearing ring · Ø inside: 22.3 mm · Color: silver · Piaggio OEM number: 190823

NTN HK1412 Needle roller bearing 14/20/12

Stock number: HK1412 · Manufacturer: NTN · Bearing type: Needle sleeve · Ø outside: 20 mm · Ø inside: 14 mm · Width: 12 mm · Dimension needle bearing: 14/20 x 12

Needle sleeve HK1412 (14/20 x 12) swingarm axle original | Piaggio SI

Manufacturer: Piaggio · Ø outside: 20 mm · Ø inside: 14 mm · Total length: 12 mm
