Spare parts catalog for the Puch Allegro models GS1, GS2 and GS2G
The complete moped was recorded in exploded drawings. Each individual component is provided with the quantity, spare part number and assembly location.
Super Swiss catalog from 1979 with 133 interesting pages.
Details
| Material | Paper |
| DIN format | A4 |
| Number of pages | 133 pcs |
| Language | German, French |
Suitable for the following models
| Puch | E50 ZA50 (air-cooled) ZA50 (fan-cooled) |
