Sachs engine & gearbox

Jasil crankshaft (L17 bearing) | Sachs 50/3 & 50/4

Manufacturer: Jasil · Cheek type: standard · Total length crankpin ignition side: 70.6 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

Housing cover small Occ. | Sachs 50/2 (Type 1)

Manufacturer: Sachs · Material: Aluminum · Surface: varnished · Color: silver · Pony OEM number: A1024 · Sachs OEM no.: 0211 069 206

swiing® revival gasket ignition cover | Sachs 503 AB, AC, ADV (A5671)

Manufacturer: swiing® revival parts · Material: Sealing paper · Number of components: 1 pcs · Thickness: 0.4 mm · Number of fixing points: 4 pcs

GPO retaining plate clutch basket Sachs

Manufacturer: GPO · Area of application: Special tool · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Total length: 135 mm · Width: 51 mm · Thickness: 4.6 mm · Ø inside: 40 mm

Meteor piston 39.2 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 39.2 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 88 g · Pony OEM number: A2776 · Sachs OEM no.: 0286 377 014

Meteor piston 38 mm | Sachs 50/2, 503 (A2772)

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.95 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Thick piston ring: 1.6 mm · Piston weight: 79 g · Pony OEM number: A2772 · Pony OEM number: A4358 · Sachs OEM no.: 0286 377 010 · Sachs OEM no.: 0286 378 005

swiing® revival rubber grommet ignition cable | Sachs 503 2AL/2BL/AAL, 535 (A4521)

Manufacturer: swiing® revival parts · Material: Rubber · Ø Cable bushing: 5.2 mm · Ø mounting hole: 8.5 mm · Ø outside: 10.5 mm · Ø Bundle: 10.5 mm · Waistband height: 3 mm · Color: black · Pony OEM number: A4520 · Pony OEM number: A4521 · Sachs OEM no.: 0960 135 000 · Sachs OEM no.: 0960 136 000

Meteor piston 37.99 mm type C | Sachs 504

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.99 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: C · Piston weight: 77 g

Meteor piston 40.0 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 40 mm · Ø outside piston (A): 39.95 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 94 g

swiing® revival gasket cylinder base 0.3 mm | Sachs 50, 50/3, 50/4 DE engines

Manufacturer: swiing® revival parts · Material: Oiled paper · Place of use: Cylinder base · Thickness: 0.5 mm · Hole pattern [mm]: 40.5 x 51

swiing® revival gasket cylinder head | Sachs 503 AB/AC/ADV

Manufacturer: swiing® revival parts · Place of use: Cylinder head · Reinforced: Yes · Nominal diameter: 38 mm

swiing® revival stud bolt M5 x 23 mm inlet (diaphragm) 10.9 | Sachs 50/2 (A3700)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Diameter: 4.9 mm · Thread type: M5x0.8 (standard thread) · Total length: 23 mm · Thread length: 6 mm · Thread length: 12 mm · Pony OEM number: A3700 · Sachs OEM no.: 0640 016 101 · Sachs OEM no.: 0640 016 102

Spacer washer 13/19/0.1 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.1 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

Oil seal NBR 24.8/31.4/4 A Brake shaft | Sachs 50

Place of use: Clutch cover · Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Ø inside: 24.8 mm · Ø outside: 31.4 mm · Width: 4 mm · Manufacturer: Sachs · Material: NBR · Surface: rubberized

Oil seal NBR 15/35/7 AS crankshaft | Sachs 504, 535 (A4214)

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 15 mm · Ø outside: 35 mm · Width: 7 mm · Manufacturer: Sachs · Material: NBR · Surface: rubberized

Jasil crankshaft | Sachs 503 AB-CH / ABL CH (A2901 / A2902)

Manufacturer: Jasil · Material: Steel · Cheek type: standard · Crankshaft stroke: 42 mm · Connecting rod length center-center: 84 mm · Total length of crankpin on clutch side: 101.15 mm · Total length crankpin ignition side: 64.1 mm · Ø crank webs: 85 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 11 mm · Dimension needle bearing: 12 / 15 x 12.8 mm (axe 12) · Wide crank webs: 30.3 mm · Length 1st paragraph: 19 mm · Length 2nd paragraph: 51 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 14 mm · Ø 3rd step (on the clutch side): 8 mm · Length of shoulder (ignition side): 34 mm · Weight: 875 g · Number of gears: 2 pcs · Area of application: Standard · Alternative version of the Pony OEM number: A2900 · Pony OEM number: A2901 · Pony OEM number: A2902 · Alternative version of the Sachs OEM number: 0288 115 002 · Alternative version of the Sachs OEM number: 0288 115 102

Gearbox cover gasket manual transmission | Sachs 50/2, 50/3, 50/4 A1827 0.4 mm (1A quality)

Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 215 mm · Width: 130 mm · Thickness: 0.4 mm · Number of fixing points: 5 pcs · Pony OEM number: A1827 · Sachs OEM no.: 0250 087 100

Crankshaft Sachs 50/3 & 50/4

Cheek type: standard · Crankshaft stroke: 42 mm · Total length of crankpin on clutch side: 42.8 mm · Total length crankpin ignition side: 70.5 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

Rubber washer under notched nail | Sachs 50/2, 503 AB/AC/ABL (A3890)

Material: Rubber · Color: black · Ø inside: 3 mm · Height: 1.8 mm · Ø outside: 10 mm · Pony OEM number: A3890 · Sachs OEM no.: 0660 002 000

swiing® ingenious lever for decompressor | Sachs 503 (A1782)

Manufacturer: swiing® ingenious parts · Color: silver · Alternative version of the Pony OEM number: A1782 · Alternative version of the Sachs OEM number: 0248 149 000

Oil seal NBR 15/30/7 B AS | Sachs 503, 50/2

Temperature resistance (min.): -30 - 100 °C · Simmering type: B - With sheet metal outer casing / one sealing lip. · Ø inside: 15 mm · Ø outside: 30 mm · Width: 7 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1830 · Sachs OEM no.: 0250 090 000

Jasil crankshaft (axe 14 mm) | Sachs 50/5 & 50/6

Manufacturer: Jasil · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Total length of crankpin on clutch side: 72 mm · Total length crankpin ignition side: 72 mm · Ø piston pin (B): 14 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread type: MF10x1 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Number of gears: 5 pcs · Number of gears: 6 pcs · Area of application: Standard

Nut & spring washer clutch hub | Sachs

Nut type: Hexagon nut · Thread type: MF12x1 (fine pitch thread) · Drive: External hexagon · Width across flats SW: 17 mm

Ignition cover (version without speedometer drive) | Sachs 50/2, 50/3, 50/4 (A1001)

Material: Aluminum · Number of fixing points: 2 pcs · Pony OEM number: A1001 · Sachs OEM no.: 0211 032 006

Spacer washer 12/18/0.1 drive wheel | Sachs 503

Ø inside: 12 mm · Nominal diameter inside: 12 mm · Ø outside: 18 mm · Thickness: 0.1 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

Engine housing 3-speed manual transmission | Sachs 50/3

Material: Aluminum · Surface: varnished · Color: silver · Stock number: E15

Karcoma decompressor M10x1.5 45° NOS

Manufacturer: Karcoma · Material: Steel · Surface: galvanized (blue) · Angle: 45 ° · Thread type: M10x1.5 (standard thread) · Thread length: 9 mm · Total length: 64 mm · Width across flats SW: 14 mm · Area of application: Standard

Wedge for flywheel | Sachs 504, 508

Total length: 9.3 mm · Width: 2 mm · Height: 3.8 mm · Material: Steel · Sachs OEM no.: 0246 005 000

Kickstarter stop | Sachs 50/3, 50/4

Material: Metal

Spacer washer 12/18/0.3 drive wheel | Sachs 503

Ø inside: 12 mm · Nominal diameter inside: 12 mm · Ø outside: 18 mm · Thickness: 0.3 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled

Ratchet wheel kickstart mechanism | Sachs

Material: Metal

ESJOT sprocket 13 | Sachs (50/3, 50/4)

Manufacturer: ESJOT · Material: Steel · Surface: raw · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Number of teeth: 13 pcs · Recording type: Ø15 x SW12 · Cranking (offset): 10.5 mm

Spacer washer 13/19/0.5 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.5 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled · Pony OEM number: A1533 · Sachs OEM no.: 0244 006 000

32 mm copper ring 30.6/37.8 flame tube | Sachs

Ø inside: 30.6 mm · Ø outside: 37.8 mm · Material: Copper

Shaft seal NBR 12.96/31.5/3.5 Pinion shaft | Sachs 50/2 (A1137)

Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Ø inside: 12.96 mm · Ø outside: 31.5 mm · Width: 3.5 mm · Manufacturer: Sachs · Material: NBR · Pony OEM number: A1137 · Sachs OEM no.: 0230 014 100

Meteor piston 38.9 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38.85 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 86 g · Pony OEM number: A2775 · Sachs OEM no.: 0286 377 013

GPO clutch plates (2 pcs.) | Sachs 50/2, 503 2AL/2BL (A3887)

Manufacturer: GPO · Material: Composite materials · Material: Steel · Recording type: Interlocking · Ø inside: 29.6 mm · Ø inside: 35.6 mm · Ø outside: 93 mm · Number of slats: 2 pcs · Thickness: 3.3 mm · Area of application: Standard · Pony OEM number: A3887 · Sachs OEM no.: 0659 010 006

Crankshaft Sachs 50/2 AML (A2733)

Cheek type: standard · Total length of crankpin on clutch side: 94.5 mm · Area of application: Standard · Pony OEM number: A2733 · Sachs OEM no.: 0286 346 000

Meteor piston 37.97 mm type A | Sachs 504

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.97 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 78 g

Ring gear 50/3, 50/4

Ø inside: 29 mm · Nominal diameter inside: 29 mm · Ø outside: 32 mm · Total length: 7 mm

Countershaft with 15 teeth fixed gear | Sachs 50/3

Number of teeth: 9 pcs · Number of teeth: 11 pcs · Number of teeth: 15 pcs · Toothing type: straight toothed · Total length: 96.6 mm

Disk 15.7/27/3 | Sachs 50/3, 50/4 Kickstarter models

Ø inside: 15.7 mm · Nominal diameter inside: 16 mm · Ø outside: 27 mm · Thickness: 3 mm · Material: Steel · Surface: blank / oiled · Sachs OEM no.: A1598 · Sachs OEM no.: 0244 110 100

Spacer washer 13/19/0.15 Pinion shaft / Kickstarter | Sachs

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 19 mm · Thickness: 0.15 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled · Pony OEM number: A1540 · Sachs OEM no.: 0244 006 007

Large idler wheel 31 teeth | Sachs 50/4

Material: Steel · Surface: Hardened · Toothing type: straight toothed · Number of teeth: 31 pcs

Crankshaft | Sachs 505, 535 A1, 535 AV (A4477)

Material: Steel · Crankshaft stroke: 44 mm · Connecting rod length center-center: 85 mm · Total length of crankpin on clutch side: 77.5 mm · Total length crankpin ignition side: 73.5 mm · Ø crank webs: 79.9 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread type: MF10x1 (fine pitch thread) · Thread length: 12 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34.3 mm · Length 1st paragraph: 18 mm · Length 2nd paragraph: 44 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 11.6 mm · Length of shoulder (ignition side): 42.5 mm · Weight: 956 g · Number of gears: 1 pcs · Number of gears: 2 pcs · Area of application: Standard · Pony OEM number: A4477

Piston 39 mm | Sachs 50/3, 50/4 fan-cooled

Nominal diameter: 39 mm · Ø outside piston (A): 38.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 27.75 mm · Curvature (D): 3.35 mm · Total piston height (E): 53.1 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 83 g

Spacer bushing gearbox Sachs 50/4

Ø inside: 16 mm · Nominal diameter inside: 16 mm · Ø outside: 20 mm · Total length: 16 mm

Thrust bearing starter clutch | Sachs 502 AL, AML / 503 AAL, AC, ADV (A1175)

Bearing type: Ball ring · Stock number: L51106 · Bearing cage: "-" Sheet steel cage ball-guided · Pony OEM number: A1175 · Sachs OEM no.: 0232 136 000

Sachs engine plate (1A quality) (etched)

Manufacturer: Made in Germany · Width: 58 mm · Height: 15 mm · Surface: etched · Shape: rectangular

Slotted nut M6 shift rod | Sachs 50/3, 50/4 foot control

Material: Steel · Surface: burnished · Nut type: Slotted nut · Thread type: M6x1 (standard thread) · Drive: Slot
